Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7
Východzia sadzba
260,3 EUR
Hlavný prehľadKey Features
AMD Socket AM5:Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
Digital twin 16+2+2 phases VRM solution
Dual Channel DDR5:4*DIMMs with AMD EXPO™Memory Module Support
WIFI EZ-Plug: Quick and easy design for Wi-Fi...
Rozpis vlastností
Tipy, kde kúpiť Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7
Na našom webe nájdete najlepšie ponuky na Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 aj praktické rady k výberu.
Kde je Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 v zľave? ⭐
212,8 EUR
Tonerpartner.sk
Nižšie si môžete prezrieť produkty podobné Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7.
189,9 EUR
Tonerpartner.sk
Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 v kategórii základné dosky môžete kúpiť v e-shope PGS.sk za výhodnú cenu 260,3 EUR.
Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 – prehľad funkcií, výhod a použitia
Tovar je aktuálne na skladeK dispozícii v našom obchode
Orientračná cena260,3 EUR
GLS3.99
ZASILKOVNA2.99
Detailné informácie a popis Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 získate na stránke PGS.sk
Recenzie produktu Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 a podrobné údaje
Key Features
- AMD Socket AM5:Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors
- Digital twin 16+2+2 phases VRM solution
- Dual Channel DDR5:4*DIMMs with AMD EXPO™Memory Module Support
- WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation
- EZ-Latch Plus:PCIe and M.2 slots with Quick Release & Screwless Design
- EZ-Latch Click:M.2 heatsinks with screwless design
- Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.
- Ultra-Fast Storage:3*M.2 slots, including 1* PCIe 5.0 x4
- Efficient Thermal:VRM Thermal Armor Advanced & M.2 Thermal Guard Ext.
- Fast Networking:2.5GbE LAN & Wi-Fi 7 with Ultra-high gain antenna
- Extended Connectivity:Dual USB4 Type-C with DP-Alt, HDMI
- CPU
- AMD Socket AM5, support for:
- AMD Ryzen™ 9000 Series Processors/
- AMD Ryzen™ 8000 Series Processors/
- AMD Ryzen™ 7000 Series Processors
- (Go to GIGABYTE's website for the latest CPU support list.)
- Chipset
- AMD X870
- Memory
- Support for DDR5 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
- 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
- Dual channel memory architecture
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
- (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
- Onboard Graphics
- Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller:
- - 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz
* Support for DisplayPort 1.4 version and HDR.
- Integrated Graphics Processor with AMD Radeon™ Graphics support:
- - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
- * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
- ** Support native HDMI 2.1 TMDS compatible ports.
- (Graphics specifications may vary depending on CPU support.)
- Audio
- Realtek® Audio CODEC
- High Definition Audio
- 2/4/5.1/7.1-channel
- * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
- LAN
- Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
- Wireless Communication module
- MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0)
- - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
- - BLUETOOTH 5.4
- - Support for 11be 160MHz wireless standard
- Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1)
- - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
- - BLUETOOTH 5.4
- - Support for 11be 160MHz wireless standard
(Actual data rate may vary depending on environment and equipment.)
- * Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.)
- ** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.
- Expansion Slots
- 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
- AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode
- AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
- AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
- Chipset:
- - 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
- Storage Interface
- 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
- AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
- AMD Ryzen™ 8000 Series- Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
- AMD Ryzen™ 8000 Series- Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
- 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x2 SSDs
- 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs
* The M2B_SB connector shares bandwidth with the M2C_SB connector. The M2C_SB connector will become unavailable when an PCIe 4.0 x4 SSD is installed in the M2B_SB connector.
- 4 x SATA 6Gb/s connectors
- RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
* RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
- RAID 0, RAID 1, and RAID 10 support for SATA storage devices
- USB
- CPU+ASMedia USB4® controller:
- - 2 x USB4® USB Type-C® ports on the back panel
- CPU:
- - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
- - 1 x USB 3.2 Gen 1 port on the back panel
- CPU+USB 2.0 Hub:
- - 4 x USB 2.0/1.1 ports on the back panel
- Chipset:
- - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
- - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- - 4 x USB 2.0/1.1 ports available through the internal USB headers
- Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x 4-pin ATX 12V power connector
- 1 x CPU fan header
- 1 x CPU fan/water cooling pump header
- 4 x system fan headers
- 3 x addressable RGB Gen2 LED strip headers
- 1 x RGB LED strip header
- 4 x SATA 6Gb/s connectors
- 3 x M.2 Socket 3 connectors
- 1 x front panel header
- 1 x front panel audio header
- 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
- 1 x USB 3.2 Gen 1 header
- 2 x USB 2.0/1.1 headers
- 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
- 1 x power button
- 1 x reset button
- 1 x reset jumper
- 1 x Clear CMOS jumper
- Back Panel Connectors
- 1 x Q-Flash Plus button
- 2 x antenna connectors (2T2R)
- 1 x HDMI port(Note)
- 2 x USB4® USB Type-C® ports (DisplayPort*)
- 1 x USB 3.2 Gen 2 Type-A port (red)
- 3 x USB 3.2 Gen 1 ports
- 4 x USB 2.0/1.1 ports
- 1 x RJ-45 port
- 3 x audio jacks
- * Actual support may vary by CPU.
- I/O Controller
- iTE® I/O Controller Chip
- H/W Monitoring
- Voltage detection
- Temperature detection
- Fan speed detection
- Water cooling flow rate detection
- Fan fail warning
- Fan speed control
- * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
- BIOS
- 1 x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Unique Features
- Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
- Support for Q-Flash
- Support for Q-Flash Plus
- Support for Smart Backup
- Bundled Software
- Norton® Internet Security (OEM version)
- LAN bandwidth management software
- Operating System
- Support for Windows 11 64-bit
- Form Factor
- ATX Form Factor; 30.5cm x 24.4cm
Objavte základné dosky v rôznych cenových úrovniach
Vaše otázky k Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 prehľadne
❓ Koľko stojí Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7?
Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 kúpite od 260,3 EUR – v ponuke obchodu PGS.sk.
❓ Kde je Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 dostupný?
Pozrite si Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 v ponuke PGS.sk – výhodná cena a rýchle doručenie.
❓ Dostanem Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 ihneď?
Ak chcete zistiť dostupnosť Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7, pozrite si ponuku e-shopu PGS.sk.
❓ Dá sa zistiť EAN Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7?
Získajte informácie o Gigabyte X870 GAMING X WIFI7, AMD X870, AM5, 4xDDR5, ATX X870 GAMING X WIFI7 cez tento EAN: 4719331865368.
