Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA
Východzia sadzba
346,1 EUR
Hlavný prehľadKey Features
Supports Intel® Core™ Ultra processors (Series 2)
Digital 8+1+2 phases VRM solution
D5 Bionic Corsa for Infinite Memory Performance
AORUS AI SNATCH : Auto-Overclocking Software by AI models
AI Perfdrive : Provides...
Rozpis vlastností
U Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA máme práve teraz len jedného predajcu. Podobné tipy nižšie.
Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA v kategórii základné dosky môžete kúpiť v e-shope PGS.sk za výhodnú cenu 346,1 EUR.
Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA – prehľad funkcií, výhod a použitia
Tovar je aktuálne na skladeK dispozícii v našom obchode
Odozva zákazníkov na Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA
Používatelia dali 5 bodov
Orientračná cena346,1 EUR
GLS3.99
ZASILKOVNA2.99
Detailné informácie a popis Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA získate na stránke PGS.sk
Recenzie produktu Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA a podrobné údaje
Key Features
- Supports Intel® Core™ Ultra processors (Series 2)
- Digital 8+1+2 phases VRM solution
- D5 Bionic Corsa for Infinite Memory Performance
- AORUS AI SNATCH : Auto-Overclocking Software by AI models
- AI Perfdrive : Provides optimal and customized BIOS preset profile for users
- Premium Compatibility : 2*DDR5 with XMP Memory Module Support
- WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
- EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
- EZ-Latch Click : M.2 heatsinks with screwless design
- Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
- New Power Monitor in HWinfo for real-time monitoring on CPU power phases
- Ultra-Fast Storage : 2*M.2 slots, including 1* PCIe 5.0 x4
- Efficient Thermal : VRM Thermal Armor Advanced with I/O ZONE AORUS LIGHTING & M.2 Thermal Guard Ext.
- Fast Networking : 2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
- Extended Connectivity : THUNDERBOLT™ 4 Type-C with DP-Alt , HDMI , DisplayPort
- PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card
- CPU
- LGA1851 socket: Support for Intel® Core™ Ultra Processors
- L3 cache varies with CPU
- * Please refer to "CPU Support List" for more information.
- Chipset
- Intel® Z890 Express Chipset
- Memory
- Support for DDR5 8800(O.C) / 8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules.
- 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
- Dual channel memory architecture
- Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate innon-ECC mode)
- Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
- Support for Extreme Memory Profile (XMP) memory modules
- Support CUDIMM memory module
- (The CPU and memory configuration may affect the supported memory types, datarate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
- Onboard Graphics
- Integrated Graphics Processor-Intel® HD Graphics support:
- - 1 x Intel® Thunderbolt™ 4 connector (USB4® USB Type-C® port), supporting DisplayPort and Thunderbolt™ video outputs
- ? When a Thunderbolt™ monitor is installed, the maximum resolution supported is 5120x2880@60 Hz with 24 bpp (single display output).
- ? When a USB4® USB Type-C® monitor is installed, the maximum resolution supported is 3840x2160@240 Hz (single display output).
- * Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™ devices that can be used is dependent on the number of the PCI Express devices being installed. (Refer to Chapter 2-6,"Back Panel Connectors," for more information.)
- * Support for DisplayPort 2.1 version and HDCP 2.3
- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz * Support for DisplayPort 2.1 version and HDCP 2.3 - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3.
- (Graphics specifications may vary depending on CPU support.)
- Support for up to triple-display at the same time
- Audio
- Realtek® Audio CODEC
- High Definition Audio
- 2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
- Support for S/PDIF Out
- LAN
- Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
- Wireless Communication module
- Intel® Wi-Fi 7 BE202 (BE200NGW M)
- - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
- - BLUETOOTH 5.4
- - Support for 11be 160MHz wireless standard
- (Actual data rate may vary depending on environment and equipment.)
- * Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.)
- ** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.
- Expansion Slots
- CPU:
- - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16
- * The PCIEX16 slot can only support a graphics card or an NVMe SSD.
- Storage Interface
- CPU:
- - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU)
- Chipset:
- - 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
- - 2 x SATA 6Gb/s connectors
- RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
- RAID 0 and RAID 1 support for SATA storage devices
- USB
- CPU:
- - 1 x Intel® Thunderbolt™ 4 (USB Type-C®) ports on the back panel
- *Support up to 40Gbps with Thunderbolt devices
- *Support up to 20Gbps with USB4 devices
- *Support up to 10Gbps with USB 3.2 devices
- Chipset:
- - 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
- - 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- - 2 x USB 2.0/1.1 ports available through the internal USB headers
- Chipset+USB 3.2 Gen 1 Hub:
- - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- Internal I/O Connectors
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 1 x CPU fan header
- 1 x CPU fan/water cooling pump header
- 1 x system fan header
- 2 x addressable RGB Gen2 LED strip headers
- 2 x M.2 Socket 3 connectors
- 2 x SATA 6Gb/s connectors
- 1 x front panel header
- 1 x front panel audio header
- 1 x speaker header
- 1 x USB Type-C® header, with USB 3.2 Gen 2 support
- 1 x USB 3.2 Gen 1 header
- 1 x USB 2.0/1.1 header
- 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
- 1 x reset jumper
- 1 x Clear CMOS jumper
- Back Panel Connectors
- 1 x DisplayPort (Note)
- 1 x HDMI port (Note)
- 1 x Intel® Thunderbolt™ 4 connectors (USB Type-C® ports)
- 3 x USB 3.2 Gen 2 Type-A ports (red)
- 2 x USB 3.2 Gen 1 ports
- 1 x Q-Flash Plus button
- 1 x RJ-45 port
- 2 x antenna connectors (2T2R)
- 2 x audio jacks
- 1 x optical S/PDIF Out connector
- (Note) Actual support may vary by CPU.
- I/O Controller
- iTE® I/O Controller Chip
- H/W Monitoring
- Voltage detection
- Temperature detection
- Fan speed detection
- Water cooling flow rate detection
- Fan fail warning
- Fan speed control
- * Whether the fan (pump) speed control function is supported will depend on the fan(pump) you install.
- BIOS
- 1 x 256 Mbit flash
- Use of licensed AMI UEFI BIOS
- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Unique Features
- Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
- Support for Q-Flash
- Support for Q-Flash Plus
- Support for Smart Backup
- Bundled Software
- Norton® Internet Security (OEM version)
- LAN bandwidth management software
- Operating System
- Support for Windows 11 64-bit
- Form Factor
- Mini-ITX Form Factor; 17.0cm x 17.0cm
Objavte základné dosky v rôznych cenových úrovniach
Vaše otázky k Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA prehľadne
❓ Koľko stojí Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA?
Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA kúpite od 346,1 EUR – v ponuke obchodu PGS.sk.
❓ Kde je Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA dostupný?
Pozrite si Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA v ponuke PGS.sk – výhodná cena a rýchle doručenie.
❓ Dostanem Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA ihneď?
Ak chcete zistiť dostupnosť Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA, pozrite si ponuku e-shopu PGS.sk.
❓ Dá sa zistiť EAN Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA?
Získajte informácie o Gigabyte AORUS Z890I ULTRA, Intel Z890, LGA1851, 2xDDR5, mini-ITX Z890I AORUS ULTRA cez tento EAN: 4719331864804.
